Product Description
Trucks of this model are the first model equipped with high-power engines in the industry and have been accepted by users after their launching on the market.
01
They are suitable for large-scale mines with stable quality, affordable price, and high availability. They are all-round mine transport equipment.
02
Anti-rolling cab, multi-level shock absorption, safe and comfortable.
03
Wide machine, large cross-section frame, professional gearbox, large-tonnage drive axle.
04
Construction machinery technology, steering and lifting system confluence, full hydraulic steering, easy operation, low failure rate, high attendance.
Specification
| Model | MT50 | MT60 | MT86H | MT96H | MT106 |
| Loading Capicity | 35000（kg） | 50000（kg） | 60000（kg） | 65000（kg） | 70000（kg） |
| Curb Weight | 19500（kg） | 26000（kg） | 31700（kg） | 33100（kg） | 35600（kg） |
| Total Weight | 54500（kg） | 76000（kg） | 91700（kg） | 98100（kg） | 105600（kg） |
| Overall Dimension（LxWxH ） | 8830×2620×3690（mm） | 8750×3320×4060（mm） | 8840×3550×4050（mm） | 8860×3670×4130（mm） | 9440×3740×4130（mm） |
| Engine Model | WP12G340E310 | WP12G430E310 | WP12G460E310 | WP13G530E310 | WP13G530E310 |
| Engine Power | 340（hp） | 430（hp） | 460（hp） | 530（hp） | 530（hp） |
| Gearbox | 9JSD150A / 7DS180 | 7DS200 | 7DS200 / FC6A210 | 8DS240A | 8DS240A |
| Axle Load | 9.5T+16T+16T | 18T+25T+25T | 20T+35T+35T | 25T+35T+35T | 25T+40T+40T |
| Tyre | 12.00R20 | 14.00-25/14.00R25 | 14.00-25/14.00R25 | 16.00-25/16.00R25 | 16.00-25/16.00R25 |
| Standard Container Volume Struck/Heaped | 22/25.5（m³） | 23.5/28.5（m³） | 29.5-34/36-40（m³） | 31.5-36/38-43（m³） | 36-39.5/43.5-47.5（m³） |
| Max. Speed Unladen/ Laden | 50/50（km/h） | 41/38（km/h） | 45/45（km/h） | 49/35（km/h） | 47/34（km/h） |
| Max. Gradeability | 32% | 29% | 30% | 30% | 30% |
| Min. Turning Diameter | 22（m） | 21（m） | 22（m） | 24（m） | 24（m） |
| Min. Ground Clearance | 293（mm） | 362（mm） | 310（mm） | 370（mm） | 370（mm） |
